EcoSmart Curved Firebox Bioethanol Fireplace Insert

Firebox Curved Indoor or Outdoor Fireplace

The Firebox is a uniquely curved, ethanol fuelled fire feature that cleverly improves upon the traditional fireplace. This eco-friendly bioethanol fireplace uses sustainable bioethanol fuel, helping you do your bit to protect our environment.

Intelligently designed for optimum heat output, flame enhancement and safety, its high-quality steel construction has been designed to complement a wide range of building materials and finishes.

This enables homeowners, architects and interior designers to create a traditional or modern look depending on the project brief.

Our EcoSmart Curved Fireplace comes with Free Fuel, that’s 40 litres of e-NRG. Please add the e-NRG to your basket. The discount will automatically be applied at checkout.

Curved Bioethanol Fireplace Key Features

• Outdoor Living: Once the domain of indoor spaces, EcoSmart’s flexible firebox designs are a stylish way to bring life to alfresco areas.

• Sliding Glass Screen: This is a safety barrier and fire shield against the wind.

• Curvaceous Design: The unique curved feature radiates heat outward for full enjoyment and maximum fuel efficiency.

• Longest Burn & Lowest Odour: Clean-burning e-NRG bioethanol fuel boasts many benefits, including long burn times and low odour.

• Bold Contrast: The black powder coat protects the stainless steel firebox and contrasts the smoke-free flame dramatically.

• Accessories Included: Operational accessories designed for safe and ergonomic fire ignition and extinguishing are included.

• Tested World Wide: Our EcoSmart Fire collection has been thoroughly tested against several global standards and are UL Listed in the USA. Certified for EU and UK in accordance with EN16647, and satisfy the ACCC Safety Mandate for Australia.

Do You Have Any Questions?

Would this be your first eco-friendly bioethanol fire? If you have any questions, please use the “Questions” tab on this page or call Allison, our EcoSmart expert, at 0800 949 4040.

Also, please check out More About Bio Ethanol; this will show you a selection of bio-ethanol fires, fire pits & burners available and their eco-friendly credentials.

What is Bioethanol Fuel?

Bioethanol or ethanol is a natural, renewable and green energy source made by fermenting the sugar and starch components of plant by-products - mainly sugarcane and crops like grain, using yeast.

It is also made from corn, potatoes, milk, rice, beetroot and recently, grapes, bananas and dates, depending on the country's agricultural strength.

Why Use Bioethanol?

There are no messy environmental pollutants like soot, smoke or ash when you choose bioethanol. No harmful fumes exist, and bioethanol can safely be used inside the house.

Burning bioethanol fuel creates a beautiful, lively, dancing orange flame that is simply mesmerizing. And because they don't need a flue or chimney, you can enjoy an open fire more easily than ever - even in a high-rise building.

Efficient Fuel Source, because e-NRG requires no venting, it is an incredibly efficient fuel source. Never lose heat up a chimney or flue again!

Is Bioethanol Fuel Sustainable?

The combustion of bioethanol results in a clean emission: Heat, steam and carbon dioxide. Plants absorb carbon dioxide. It is then processed via photosynthesis to help the plant grow.

This infinite cycle of creation and combustion of energy makes bioethanol a carbon-neutral fuel source.

Curved Firebox

The Curved Firebox is available in two sizes, the 1100CV and 1400CV. Both have the following features:

• Application: Indoor & Outdoor

• Materials: Mild Steel, Toughened Glass

• Model Colour: Black

• Burner Colour: Stainless Steel

Curve Firebox 1100CV with XL900 Burner:

• Weight 61.50kg

• Model Dimensions in W 134cm D 37.1cm H 85cm

• Viewing Area in mm W 134cm D 32.1cm H 85cm

• Full 1100CV Curved Firebox brochure

Burner Efficiency (XL900)

• Capacity: 9 L [2.4 Gal]

• Heats on Average: 60m2

• Minimum Room: 110m3

• Burn Time: 8-13h

• Thermal Output: 16 MJ/h - 15000 BTU/h - 4.4 kW

Curve Firebox 1400CV with XL1200 Burner:

• Weight 71.70kg

• Model Dimensions in W 164cm D 37.2cm H 85cm

• Viewing Area in mm W 164cm D 32.1cm H 85cm

• Full 1400CV Curved Firebox brochure

Burner Efficiency (XL1200)

• Capacity: 10 L

• Burn Time: 9-14h

• Thermal Output: 17 MJ/h - 15290 BTU/h - 4.5 kW

Maximum Safety

EcoSmart Fireplaces are very safe and have a built-in flame arrester; some simple operating procedures and accessories allow for safe and easy fireplace refuelling.

Accessories Included:

The EcoSmart Fire Curved Firebox comes with the following accessories included in the price.

Fire Lighter

This refillable butane lighter supports the safe ignition of the lighting rod. The length of the lighter further enhances the management of the lighting process.



Lighting Rod

This operational accessory enables you to safely adjust the slider position of the Burner at any time. It is also used for ignition and extinguishing procedures.

Jerry Can 5L

Safety features include automatic stop flow, fast flow rate, locking thumb button control and self-venting system.

Black Glass Charcoal

The Black Glass Charcoal is made from high-quality tempered glass and has been designed to withstand harsh weather and temperatures of up to 1300ºF/700ºC.

Bottle Adaptor

The adaptor connects the safety spout from the Jerry Can straight onto the e-NRG bottle making fuelling the fire quicker and easier.

Choose the Right Fuel - Use e-NRG bioethanol

It is essential that you choose the right fuel. e-NRG bioethanol is the ONLY fuel suitable for use in your EcoSmart Fire. You can purchase e-NRG bioethanol on EcoFire.co.uk.

What is e-NRG?

Formulated for use in ventless ethanol fireplaces, e-NRG is the cleanest, most efficient liquid bioethanol fuel on the market and produces the best flame each and every time.

Green e-NRG produces no harmful emissions - just heat, steam, and carbon dioxide.
